Részletek
FREQUENCY RESPONSE
20Hz to 20kHz +/- 0.2dB
SIGNAL TO NOISE RATIO
-80dB at rated input level, A weighted
DISTORTION
<0.05% THD at rated input level
INPUT SENSITIVITY FOR RATED OUTPUT
125mV RMS Unbalanced Inputs
62mV RMS Balanced Inputs
INPUT IMPEDENCE
50k ohms
RATED PRE OUT LEVEL
500mV RMS into 10k ohms or higher
PRE OUT MINIMUM RECOMMENDED LOAD
47k ohms
LINE OUT LEVEL
190mV at 200 ohms
OUTPUT SOURCE IMPEDENCE
Typically 100 ohms
GAIN
Line Ampilfier: 12dB
POWER/CURRENT CONSUMPTION
40W
0.10A (23W) idle/standby
INPUT CAPACITANCE
100pF
ADJUSTABLE GAIN
60dB, 66dB
ADJUSTABLE LOAD
47k ohms, 470 ohms, 100 ohms, 47 ohms, 22 ohms
DIMENSIONS
Height: 105mm (4")
Width: 450mm (17.5")
Depth: 400mm (15.75")
Weight: 9kg (20lbs)
